Thanks for the tip about the Plano storage box. I bought one yesterday to replace the two milk crates that I stored in the inner-most part of the basement. Even with ropes attached to the crates to make it easier to remove them, the furthest crate would always hang up on a bump in the ridged rubber matting, and I would have to go headfirst into the basement to retrieve it. The Plano box slides in and out easily, once you figure out how to angle it just right.
-
water pump chattering at end of cycle
Fargoman replied to nrvale0's topic in Mechanical & Technical Tips
What do I need to do before removing and cleaning the water pump filter to avoid spilling water? I've read enough posts about plastic shavings in the filter that made me want to check, even though I haven't noticed any water flow problems. -
Hi John. I did not drill drain holes in the bottom of the support bars. The plugs are only in the outer exposed ends, so any water that gets into the bars should drain or evaporate from the open inner ends under the trailer. Thanks again for the inspiration to make this modification.
-
I finished installing mud flaps on our 2021 LE2 today. The street side mud flap does not clear the basement door, as on JED's trailer, but the door does open fully when the upper part of the flap is bent forward a bit. That's not a big deal, but I do wonder what the difference is between our trailers. The 1"x2" aluminum tubing I used is attached to the forward part of the lateral angle that is part of the sub-frame, and the flap is attached to the front of the aluminum support as in the photos of other installations. I suspect that the lateral angle piece is welded to the sub-frame further to the rear of the trailer, rather than there being a difference in the size of the basement door opening. I added plugs to the exposed ends of the aluminum supports to give a more finished appearance. I bought them on Amazon (where else?). https://www.amazon.com/gp/product/B07CNCCR7S/ref=ppx_yo_dt_b_asin_title_o01_s00?ie=UTF8&psc=1
-
Girard Power Awnings Pitch Adjustment
Fargoman replied to Fargoman's topic in Mechanical & Technical Tips
I finally got around to adjusting the pitch of the two awnings today. Instructions were on pages 197 to 199 in the 2021 Legacy Elite 2 Standard Features manual. I wanted both awnings to be lower at the rear of the trailer so water would run off in that direction, and away from the entry door on the curb side. The curb side awning was already somewhat lower to the rear of the trailer, but I increased the pitch to lower it slightly more. The street side awning was pitched in the opposite direction, which didn't really matter since there is no door on that side, but I like symmetry, so I adjusted them to be the same. The adjustment is really easy, and you almost don't need to use a 17 mm wrench. With the awning fully extended, and lifting the awning arm slightly to relieve pressure on the adjusting cam, I was able to turn nut by hand (CW to raise, CCW to lower whichever arm you're adjusting). Like many mechnical tasks, it took longer to figure out how to do the job than to perform the job. I didn't need to adjust the elbow height of the hinged support arms, because they still retracted properly after adjusting the pitch. -
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
The replacement zerk fitting did not solve the problem of the wet bolt accepting grease, so I submitted a ticket to Oliver. Jason responded quickly, saying that they would send a replacement bolt, and that I could replace the bolt myself, or have a local service facility do the work and submit a reimbursement claim to Dexter. Coincidentaly, two days earlier a friend had highly recommended a local family-owned RV service facility, so I opted to have them perform the work. When I went there to schedule the repair, they told me to bring the trailer by that afternoon so they could determine if the bolt was truly faulty, or just needed a more powerful grease gun than the mini-grease gun I use. The bolt was indeed faulty, and they had a replacement in stock (the one from Oliver had not yet arrived), so they set about replacing the bolt. It took close to an hour, but they only charged for half an hour of labor (work stopped for a while as everyone in the shop had to come inspect and drool over my exotic fiberglass trailer. A happy ending to a small, but nagging problem, and I now have a trusted local repair facility to turn to when things get above my pay grade. Attached is a photo of the offending bolt. I'm not sure if the wear is normal after only 3500 miles or indicative of a lack of sufficient grease. -
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
Thanks for pointing that out Frank. In retrospect, knowing that there are two E-Z Flex links per side I should have looked further. I had seen an earlier post about zerk fittings that mentioned a total of 14 and figured that "Hey, I found the two hidden ones!" -
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
I couldn't un-stick the zerk that wasn't accepting grease, and decided to replace it. When I removed the curb-side rear wheel to make it easier to get a ratcheting socket on the zerk, I discovered that there are 14 zerk grease fittings, not 12 as mentioned in my original post. With both wheels on I hadn't noticed the 'hidden' zerk on the bolt that attaches the E-Z Flex system to the subframe. I had assumed that bolt would have had a zerk in the bolt head like the bolts that attach the leaf springs to the E-Z Flex, like in John Davies photo above. I mention this with the hope that some other new owner realizes that there are two zerks that are not readily visible without removing a rear wheel or crawling under the trailer. -
Seeing an Oliver in the West is definitely a rare event, but maybe I'm just easily excited. 2008RN, I live in Redding, CA. With my grown kids living in Portland, OR and Vancouver, WA I expect to be taking my Ollie on many camping trips in the Northwest. A Northwest Oliver rally is a great idea.
-
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
Regarding jacking one set of tires off the ground to relieve pressure on the suspension (using either floor jack or built in leveling jacks), is it OK to leave the front of the trailer supported only by the front leveling jack? There would be some slight angular force on the front jack by doing so. I hitched the trailer to my TV the first time I raised one set of tires off the ground just to be cautious. -
We have the Furrion wireless backup camera, ordered as an option when we took delivery of our 2021 LE2 last September. The display is mounted on the windshield just above the dashboard, and with the brightness & contrast of the display maximized, I still find the display hard to see in most daylight driving conditions, when the view through the windshield is fairly bright. On overcast or rainy days when the view through the windshield is darker, the display brightness is acceptable. Has this been an issue for any of you?
-
They do exist! We finally saw an Ollie LE2 this afternoon while returning home from Vancouver, WA today. This was the first Ollie we have seen since taking delivery of our LE2 last September. We were heading south on Interstate 5 about 30 miles north of Eugene, OR, and the Ollie was northbound, around 12:30 PM. Any ideas who it might have been?
-
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
Thanks Bill, I'll try your suggestion before replacing the zerk. -
Dexter EZ-Flex zerks not accepting grease
Fargoman replied to Fargoman's topic in General Discussion
Thanks to all who responded. I did jack the wheels on the curb side off the ground today to unload the suspension where two zerks weren't accepting grease. One zerk took grease, but one did not, so I will replace it to see if that solves the problem. -
Greetings from new owner in Washington State
Fargoman replied to Landsplash's topic in Introduce Yourself
Thanks. Galway Girl. I enjoyed your post about your trip to the Oliver factory, and have bookmarked several Northwest campgrounds that you described.
