Townesw

Are you looking for the fan motor data label or the model and SN of the whole fan? This is the model of the whole fan on 2019 hull 313. Remove the screen and you will see this label.

Do this from the inside. Remove shades. Slide screen to middle of window frame. Grasp lower left and lower right corners of screen frame. Lift the lower corners at the same time so that the bottom of the screen frame clears the track. Pivot the lower edge of the screen frame towards you and drop the top edge of the screen frame out of the top track. The rear screen is different. It has 2 clips on the bottom and 2 clips on the top. If trailer is not on fire, gently pull on the bottom frame until clips release then the top of the frame will fall free. The rear screen does not fit in a track so note the positions of the clips before removing the screen. If trailer is on fire, grab the red trapezoidal shaped tab, yank the screen out, fling it to the side, then dive head first out the window.

For years our MaxxFan 7000K has made a high pitched chirping noise at lower speeds. I had been told that it was due to pulse width modulation speed control so I didn’t try to fix it. My wife can’t hear the noise but it really annoys me. I finally googled and found this video. I cleaned the brush dust out of the motor and now the fan is pretty quiet. Be aware that black dust will come out of the motor when it is disassembled so you might have someone hold something under the motor as you pull it apart.

@Geronimo John look inside the rear bumper. There is a rubber seal around the sewer pipe where it goes into the lower left rear of the trailer that will become dislocated and permit dust intrusion. Reposition the seal and place a clamp around the sewer pipe to keep the seal from slipping back out of the hole. I used a Stainless steel Banjo TC-331 just snug. Not tight.

Summary: Check under your kitchen sink I walked up to an Oliver at a campground one time to introduce myself. I noticed water running down the curb side rear stabilizer. After exchanging greetings I brought the leak to the attention of the owner. After looking under the curb side bunk and finding nothing I suggested that he look under the kitchen sink for the source of the leak. Upon removal of the drawers he found water soaked plywood caused by a loose coupling on the kitchen sink drain trap. Since then I have tried to check mine occasionally to ensure that it is tight and to look around for any other problems. Today I found that the quarter turn stop on the hot water was not completely open. It had probably been like that since we took delivery. Anyway, I opened it and improved the hot water flow at the sink. Occasionally remove your (kitchen) drawers and check on stuff down there -tightness of the drain coupling -quarter turn stops fully open -refrigerator plug plugged in -hose weight located between back of drawers and rear of cabinet carcass -hose not twisted -any sign of moisture -anything rubbing against something -and especially that blue clip on the faucet hose assembly. There was an owner that heard water running underneath her sink when she turned the faucet on. Turns out that blue clip was missing and the hose had completely separated. We have a 2018 OEII, hull 313. Some of this stuff has probably changed. The round port was added after production to access a loose clamp on the exit end of the fresh tank overflow hose. It sure is useful for checking below the cabinets. There is a plumbing vent under the back right corner of the range. It is supposed to let air in and not let grey tank smells out. If you are smelling something foul (grey tank odors, not black tank odors) and you can’t locate a leak you might have a bad plumbing vent.

Here is the response I received from Jason in July 2019 regarding faucet model number used in Hull 313. Here’s the cartridge I used. Get a couple of spares. I ordered one from Amazon and Dura sent me one under warranty. I need to replace mine again. https://www.amazon.com/Dura-Faucet-DF-RK601-Cartridge-Replacement/dp/B072BVH7KB Don’t forget the socket wrench. Mine came from a set that I bought at a Menards in Marquette MI. It’ll make the job real easy. You may have to clock the faucet base if it has been twisted out of position. See my write up in this thread.

I asked service what was being used and the response was ASI 335.

Read my posts in this thread for installation of a replacement without drilling holes. The LP/CO detector shown in the thread is what the service department was recommending at the time.

I realize this post has nothing to do with the direction this thread has taken, but I think this part is what was originally used for the bathroom sink drain. I submitted a service request asking for the correct part but the factory was unable to provide that information. You won’t find this in most hardware stores. https://www.lasallebristol.com/product/metal-c-o-plug-without-overflow/

@jd1923 That same regulator package, F3004 from RV Water Filter Store, was $138, shipped, in July 2019. I don’t know where it was made. Google “Camco water pressure regulator vs. diaphragm water pressure regulator” and read some of the discussions that pop up. This is one that I found: https://www.irv2.com/forums/f54/water-pressure-regulators-255560.html We primarily use full hookups, so this isn’t going to help if you’re using the pump.

@Geronimo JohnThat water is not pumped water. Those videos are with trailer hooked to city water through a hose bib on the house. One video with water flowing through a brass Camco “pressure regulator”, which I call a flow restrictior, and the other video with water flowing through a Watts pressure regulator.

Are they still using ASI 335? This stuff works well for removing old caulk

@Lisa Rae @jd1923 I have hull 313. I have 2 check valves under the basement floor just under the door. This is a picture that I made in September 2019 of mine when a few Olivers were having problems with split check valves. I’ve not found any of the brass Camco “pressure regulators” down there. The plumbing diagram shows the check valves but doesn’t show any “pressure regulators”. Oliver provided a brass Camco “pressure regulator” (or flow restrictor) for use externally to limit the incoming water pressure and I used it when our trailer was new. We noticed that when we turned on any water that the flow would be strong and then it would quickly slow. I did some reading on the internet that lead me to replace the “pressure regulator” with a diaphragm type pressure regulator. Video from July 2019, flow with Camco pressure regulator in place at the city water faucet (hose bib). IMG_4032.mov Video from July 2019, Watts diaphragm type pressure regulator in place at the city water faucet (hose bib). IMG_4034.mov I am the kind of person that likes to know how things work and I have thought about cutting the flow restrictor (Camco “pressure regulator”) open to see how it works but, it is my backup in case my Watts regulator fails. (Boy Scout motto: Be Prepared). All of my information and suggestions come with the added warning that what worked in my case may not work for you.

I got better flow everywhere in the Oliver when I switched from this to this https://www.rvwaterfilterstore.com/products/263a-lf-regulator-stainless?_pos=1&_sid=7382cb9a5&_ss=r

Thanks @mossemi I did see that thread but I’m on my second caddy from the factory and both appear to have been hand trimmed when manufactured. The edge that meets the front of the vanity is so wavy that I doubt that I could get a seal on the edge to seal well against the vanity. What did you use to enlarge the hole for the hatch?
