Mountainman198

Good news and thanks for the road trip update. My Alcans are installed and I have a 1,700 mile trip scheduled for later this month. I too am looking forward to the peace of mind over the poor performance of the EMCO spring packs that came on my E2. Did you notice any negatives from towing with the 2,000 vs. 1,750 rated spring packs?

Mine were 1/2”x3” and the new ubolts provided by Alcan were 9/16”x3”. Fit perfect. Longer to accommodate taller Alcan spring packs. 9/16” fit thru spring retainer plates fine as holes are larger than 1/2”

Mike in Oliver Service had asked for the specs and contact info for the US made springs I had found as he said they were not aware of any US sourced suppliers and would be interested in what I had found. I told him I would send the info once I had them on my trailer. I forwarded the specs and some pics along with Alcan contact info to him today and he said he would pass it along within Oliver.

I think the answer you got is technically correct, but I do not believe the axle assemblies provided to Oliver by Dexter contain spring packs manufactured by the Dexter Parent company. For example, the springs on my trailer were stamped “EMCO”. If you do a google search you will find that while EMCO is a US based company, they have a 200,000 sq ft Spring plant in the Hebei Province in China which serves the US market. At least for my trailer, I am fairly certain this was the manufacturing plant for my Springs. https://emcoind.com/about-us/

First side is swapped. Old Chinese Dexters will go to the recycler and bring scrap value…maybe enough for a soda pop. A few observations: 1) I put a set of calipers to my 3500# Dexter axles and they are 3” dia. Ubolts provided by Alcan are for 3” dia axles fit perfect 2) Alcan ubolts are 9/16” rod vs. the smaller (1/2”?) that were stock on my trailer. No worries installing as the holes in the spring retainer plate are large enough to accommodate the larger bolt diameter 3) Alcan ubolts are longer to accommodate increased spring pack height (5 vs. 4 leafs). About 1-1.5” of thread extend below nuts. I plan to leave but you could cut the excess off if it bothers you 4) Torque specs from Alcan for 9/16 ubolts is 90 foot lbs. See attachment 5) Two of my shocks were blown so I am replacing them A Irwin squeeze clamp works wonders for compressing and installing the shocks after the springs have been bolted in 6)reversed the wet bolts so that the zerks point inward even with a 90 degree lock-n-lube fitting it was a PITA before hoping this will be easier 7) the front springs were still in “ok” shape but starting to flatten. one rear spring had snapped and the other was bent 8)the parts for my trailer were sourced during COVID and at the height of demand for RVs. I cannot help but ponder if the RV frenzy and skilled labor shortage during this time played some role in my broken spring and the quality of the other one that was bending. Oh well, just glad to be safe and be replacing the stock springs before heading out in a month for another Season of seeing this great Country Very straight forward swap. Heck, I did it on a tarp in melting CO permafrost. Cannot imagine doing the swap inside on concrete. 🤪 That would be Lux.

I will not be able to get the measurement as rear springs have already been changed day after my rear two springs failed in Feb. I believe Hobo reported a 3/4” change (higher) at the bumper after his change to Alcan (but this may be partly due to flattening of old springs over time?) 1” clearance, WOW. You gotta be doing some serious glute squeezes through that opening in/out at stock height.

Trusting that RVIA has the consumers interest and safety at forefront is akin to expecting that NADA (North American Automotive Dealers Association) has the end consumers interest at heart. Prepping to finally install my Alcan springs today now that the snow has melted. 😀

I stopped the guy who was skijoring down the street behind a Subaru and he agrees with your assessment.

I could have been wrong in which case you had the unicorn nev-r-lube fitment on 3500# axles. 💪

Please correct me of I am wrong, but the suspension arrives to Oliver as an assembly and is rated as the assembly (springs plus axles) and given the lower of the two of axle rating or spring rating. It appears you have D52 (5200lb) axles with 3500 lb springs which as an assembly are correctly rated at 3500 lbs.

Mike from ALCAN assured me that the springs they sold me were 2,000lb springs. So, 2,000x4= 8,000. 3,000 lb springs could be a issue. For full disclosure, my E2 is a 2021 with approx 25,000 miles towed. 99%+ of miles were on paved roads, 80% of those miles is West of Mississippi, remainder of miles is in the Summer. Never on either Coast. Dry weight of my trailer is just over 5,250 lbs. All three tanks are empty whenever I travel. Trailer rides level using Andersen hitch.

Located 8,750’ up in the CO Rockies. We get 300+ days of sun here so why won’t my solar panels produce power?

They did not offer the couch cushions in 2021 when I ordered either. I use a set of four down throw pillows which allow me to create different shapes for sitting/leaning differently

I believe Hobo has posed this question to ALCAN. I dont know the answer, I would PM him or give ALCAN a call. They may be able to recommend a local installer. Please report back your findings

For example

I completely understand where you are coming from. However, coming from a rock crawling and jeeping background I can understand the warranty period for their products as their main business is building custom suspensions for people who will take their 4x4 rigs to places like Moab and do things to them that a teenager wouldn't do to a stolen rental car. Over time and as ALCAN gets more into the RV suspension business, perhaps their RV spring warranty will split from their off-roading line and fall more in line with that which we are used to seeing in our world. Until then and knowing what their rock crawling customers do to their products and that the springs I purchased for my trailer are built with the same raw materials and using the same process as their offroad springs I am confident of my purchase.

Given that the Dexter (EMCO, TexTrail) springs are only $70/pr, I felt my time better spent playing guitar and drinking coffee than documenting and substantiating the claim to Dexter only to possibly be rewarded with another set of their springs.

Mike from ALCAN just called to let me know that all future orders of springs for Olivers will have the centering pins in the correct orientation for our trailers. He asked that I alert those who have ordered and who may order in the future to state the springs are for a Oliver E2. I had sent him an email asking about my understanding of how to flip the centering pins on my springs. He confirmed that flipping the pins is as simple as MountainOliver explains with a couple of C clamps, wrench, and hammer. Hopefully, I am the only Oliver owner to have to perform this step moving forward.

The wet bolts from my Oliver are 9/16" O.D. and from my measurement of the ALCAN springs I received I am re-using my existing wet bolts as the I.D of the bronze bushings in the ALCAN springs I received are 9/16". Let me know if this does not make sense. I chose NOT to buy new wet bolts from ALCAN.

I don't know about the other owners who have experienced a broken spring(s) but I opened a ticket the day after it broke and remained in contact with them until I sourced new springs.

Agree. Has anyone checked out the lead provided for St. Louis Spring? They seemed capable of replicating our springs with US Steel. Has anyone identified additional US Spring manufacturers who can build to our specs in US 5160 steel?

I can confirm that these measurements match the OEM brand/model spring specs for Hull #898 as well as match the published specs for the replacements spring brand/model provided by Oliver Service for my trailer. I encourage owners to confirm the specs of their OEM springs to know what they are replacing before proceeding with replacement of any part as we know certain differences exist between out trailers based in hull# and date produced. My OEM Spring make/model was conveniently stamped into the retainer band towards the end of each of my leaf springs (see pic). From this info I did a google search and found the specs. The springs installed at the factory on Hull #898 were made by EMCO and are model #PR-4B. The specs match what Steve provided above. Added to the specs Steve provided is the bushing spec provided by Oliver. The bushing is inserted into the spring eye and our wet bolts ride inside of them. The specs for these bushings (whether plastic or bronze) is 1.75”L, 11/16 O.D.(outside diameter) and 9/16”I.D.(inside diameter). It should be noted that the bronze bushing on the ALCAN springs is thicker walled than standard such that while it still has a 9/16”I.D., the spring eye into which it is pressed is larger than 11/16”. The 9/16”I.D. Of the bushing is important on these metrics as our wet bolts (which are 9/16” must fit inside the bushing eye) I hope this makes sense. I have attached a pic for comparison OEM spring in top, ALCAN on bottom.

Same here. One was bad so I bought a pair of the same model monroe. Could not find a better shock as nothing cross-references with it. Anyone have a better shock please provide make and part number

not in my situation. The ubolts rested on the steel carrier which is bolted to the frame. I could still place my fingers between the tires and the fiberglass flares on both sides. Note: it was my LR spring that failed. Might be different spacing for front failure?

Good catch. You are correct that the springs I have appear to be set up for Spring Over Axle rather than Spring Under Axle. Thanks for alerting us to this. Agree not a big deal, just another step which could be resolved on their end during assembly via a request at order time.
